离线安装 Kubernetes 和 KubeSphere 企业版

tar -zxvf <package name>

cd <directory>

sudo chmod +x kk

vi config-sample.yaml

apiVersion: kubekey.kubesphere.io/v1alpha2
kind: Cluster
metadata:
  name: sample
spec:
  hosts:
  - {name: controlplane1, address: 192.168.0.2, internalAddress: 192.168.0.2, port: 23, user: ubuntu, password: Testing123, arch: arm64} # arm64 节点注意添加参数 arch: arm64
  - {name: controlplane2, address: 192.168.0.3, internalAddress: 192.168.0.3, user: ubuntu, privateKeyPath: "~/.ssh/id_rsa"}
  - {name: worker1, address: 192.168.0.4, internalAddress: 192.168.0.4, user: ubuntu, password: Testing123}
  - {name: worker2, address: 192.168.0.5, internalAddress: 192.168.0.5, user: ubuntu, password: Testing123}
  - {name: registry, address: 192.168.0.6, internalAddress: 192.168.0.6, user: ubuntu, password: Testing123}
  roleGroups:
    etcd:
    - controlplane1
    - controlplane2
    control-plane:
    - controlplane1
    - controlplane2
    worker:
    - worker1
    - worker2
    # 如需使用 kk 自动部署镜像仓库，请设置 registry（建议镜像仓库与集群节点分离部署，减少相互影响）
    registry:
    - registry
  controlPlaneEndpoint:
    internalLoadbalancer: haproxy # 如需部署⾼可⽤集群，且⽆负载均衡器可⽤，可开启该参数，做集群内部负载均衡
    domain: lb.kubesphere.local
    address: ""
    port: 6443
  kubernetes:
    version: v1.23.15
    clusterName: cluster.local
  network:
    plugin: calico
    kubePodsCIDR: 10.233.64.0/18
    kubeServiceCIDR: 10.233.0.0/18
    ## multus support. https://github.com/k8snetworkplumbingwg/multus-cni
    enableMultusCNI: false
  registry:
    # 如需使用 kk 部署 harbor，可将该参数设置为 harbor，不设置该参数且需使用 kk 部署容器镜像仓库，将默认部署 docker registry。
    # harbor 不支持 arm64，arm64 环境部署时，可不配置该参数。
    type: harbor
    # 如使用 kk 部署的 harbor 或其他需要登录的仓库，需设置对应仓库的 auths，如使用 kk 部署默认的 docker registry 仓库，则无需配置 auths 参数。
    # 注意：如使用 kk 部署 harbor，auths 参数请于创建 harbor 项目之后设置。
    auths:
      "dockerhub.kubekey.local":
        username: admin # harbor 默认用户名
        password: Harbor12345 # harbor 默认密码
        plainHTTP: false  # 如果仓库使用 http，请将该参数设置为 true
    privateRegistry: "dockerhub.kubekey.local/kse"   # 设置集群部署时使用的私有仓库地址
    registryMirrors: []
    insecureRegistries: []
  addons: []

spec:
  hosts:
  - {name: registry, address: 192.168.0.6, internalAddress: 192.168.0.6, user: ubuntu, password: Testing123}

bash create_project_harbor.sh

mkdir /etc/containerd

# 创建 containerd 配置文件
# 注意修改 sandbox_image 以及 [plugins."io.containerd.grpc.v1.cri".registry.configs]
# 下的仓库信息为实际环境信息

cat <<EOF > /etc/containerd/config.toml
version = 2
root = "/var/lib/containerd"
state = "/run/containerd"

[grpc]
  address = "/run/containerd/containerd.sock"
  uid = 0
  gid = 0
  max_recv_message_size = 16777216
  max_send_message_size = 16777216

[ttrpc]
  address = ""
  uid = 0
  gid = 0

[debug]
  address = ""
  uid = 0
  gid = 0
  level = ""

[metrics]
  address = ""
  grpc_histogram = false

[cgroup]
  path = ""

[timeouts]
  "io.containerd.timeout.shim.cleanup" = "5s"
  "io.containerd.timeout.shim.load" = "5s"
  "io.containerd.timeout.shim.shutdown" = "3s"
  "io.containerd.timeout.task.state" = "2s"

[plugins]
  [plugins."io.containerd.grpc.v1.cri".containerd.runtimes.runc]
    runtime_type = "io.containerd.runc.v2"
    [plugins."io.containerd.grpc.v1.cri".containerd.runtimes.runc.options]
      SystemdCgroup = true
  [plugins."io.containerd.grpc.v1.cri"]
    sandbox_image = "dockerhub.kubekey.local/kse/kubesphere/pause:3.6"
    [plugins."io.containerd.grpc.v1.cri".cni]
      bin_dir = "/opt/cni/bin"
      conf_dir = "/etc/cni/net.d"
      max_conf_num = 1
      conf_template = ""
    [plugins."io.containerd.grpc.v1.cri".registry]
      [plugins."io.containerd.grpc.v1.cri".registry.mirrors]
        [plugins."io.containerd.grpc.v1.cri".registry.mirrors."docker.io"]
          endpoint = ["https://registry-1.docker.io"]
        [plugins."io.containerd.grpc.v1.cri".registry.configs]
          [plugins."io.containerd.grpc.v1.cri".registry.configs."dockerhub.kubekey.local".auth]
            username = "admin"
            password = "harbor2345"
            [plugins."io.containerd.grpc.v1.cri".registry.configs."dockerhub.kubekey.local".tls]
              ca_file = ""
              cert_file = ""
              key_file = ""
              insecure_skip_verify = true
EOF

# 重启 containerd
systemctl restart containerd

vi /etc/hosts

<registry IP address> dockerhub.kubekey.local
